Product Description
testo 175T3 - Temperature data logger
Description
- Dual external thermocouple probe ports (1 Type T, 1 Type K) compatible with a variety of different probes
- Data transfer possible using the USB port, or SD card (optional)
- Easy to read large display that shows current reading and exceeded measurement limits
- IP65 proection class
- Capable of CFR 21 Part 11 Compliancy
- Free data logger software available for download
- Data is secured within the logger, and can be password protected using ComSoft
- Includes lockable wall mount to prevent theft or tampering
Delivery Scope
testo 175T3 temperature data logger, batteries, wall mount, lock, and certificate of conformity
Your advantages
-
Professional software with Excel export function for programming the logger and data analysis
-
Temperature measuring range from -50 °C to +1000 °C
-
Wall mount
-
Automatic measuring data backup when the battery runs out or is changed
-
Transfer of measuring data via SD card
-
Displays violations of limit values
The testo 175T3 temperature data logger features a large display and alarm indication that makes it ideal for continuous monitoring of temperatures. The 175T3 temperature measurement logger has dual external thermocouple connections, 1 Type K and 1 Type T, which allows for simultaneous measurements using a wide variety of probes. Creation of Excel Spreadsheets, PDFs, and data analysis are all easily achieved with the free, downloadable ComSoft software.
Technical data
Temperature - Type K TC
| Measuring range |
-58° to 1832 °F / -50 to +1000 °C
|
|---|---|
| Accuracy |
±0.9 °F (-58° to 158 °F) ±1 Digit / ±0.5 °C (-50 to +70 °C) ±1 Digit
±0.7 % of mv (158.2° to 1832 °F) ±1 Digit / ±0.7 % of mv (+70.1 to +1000 °C) ±1 Digit
|
| Resolution |
0.1 °F / 0.1 °C
|
Temperature - TC Type T (Cu-CuNi)
| Measuring range |
-58 to +752 °F / -50 to +400 °C
|
|---|---|
| Accuracy |
±0.9 °F (-58° to 158 °F) ±1 Digit / ±0.5 °C (-50 to +70 °C) ±1 Digit
±0.7 % of mv (158.2° to 752 °F) ±1 Digit / ±0.7 % of mv (70.1 to +400 °C) ±1 Digit
|
| Resolution |
0.1 °F / 0.1 °C
|
General technical data
| Weight |
4.59 oz. / 130 g
|
|---|---|
| Dimensions |
4 x 2 x 1 in. / 96 x 54 x 29 mm
|
| Operating temperature |
-4° to 131 °F / -20 to +55 °C
|
| Protection class |
IP65
|
| Channels |
2 external
|
| Housing |
Plastic
|
| Product colour |
Black
|
| Standards |
EU-guideline 2014/30/EU; 2011/65/EU
|
| Measuring rate |
10 s - 24 h
|
| Battery type |
3 x AIMn type AAA or Energizer
|
| Battery life |
3 years at 15 min. meas. rate, +25 °C
|
| Memory |
1,000,000 measuring values
|
| Storage temperature |
-4° to 131 °F / -20 to +55 °C
|
