  • testo 175H1 - Temperature and humidity data logger
  • testo 175H1 - Temperature and humidity data logger
  • testo 175H1 - Temperature and humidity data logger
  • testo 175H1 - Temperature and humidity data logger
  • testo 175H1 - Temperature and humidity data logger
  • testo 175H1 - Temperature and humidity data logger

    • testo 175H1 - Temperature and humidity data logger

    $495.00
    SKU:
    0572 1754
    Width:
    10.43 (in)
    Height:
    4.72 (in)
    Depth:
    2.56 (in)
    Adding to cart… category.add_cart_announcement

    Product Description

    testo 175H1 - Temperature and humidity data logger

    Description

    The testo 175H1 is an ideal data logger for the continuous monitoring of ambient temperatures and humidity. With its customizable alarm, the 175H1 will alert when user defined thresholds have been exceeded.
    • Internal thermistor for temperature and capacitive humidity sensor
    • Data transfer possible using the USB port, or SD card (optional)
    • Easy to read large display that shows current reading and exceeded measurement limits
    • IP54 proection class
    • Capable of CFR 21 Part 11 Compliancy
    • Free data logger software available for download
    • Data is secured within the logger, and can be password protected using ComSoft
    • Includes lockable wall mount to prevent theft or tampering
    Please note: The testo 175H1 temperature measurement logger requires an interface to use the free data logger software. One interface can be used for multiple instruments..

    Delivery Scope

    testo 175H1 temperature data logger, batteries, wall mount, lock, and certificate of conformity
    Your advantages
    • Professional software with Excel export function for programming the logger and data analysis
    • Round-the-clock monitoring and logging of temperature, relative humidity and dew point
    • Temperature measuring range from -20 °C to +70 °C
    • Automatic measuring data backup when the battery runs out or is changed
    • Transfer of measuring data via SD card
    • Displays violations of limit values
    The testo 175H1 temperature and humidity data logger features a large display and alarm indication that makes it ideal for continuous monitoring of ambient temperature and humidty. The 175H1 has an external, stub type humidity sensor, making it best-suited for use in high humidity areas. Creation of Excel Spreadsheets, PDFs, and data analysis are all easily achieved with the free, downloadable ComSoft software.

    Technical data

    Temperature - NTC

    Measuring range
    -4° to 131 °F / -20 to +55 °C
    Accuracy
    ±0.7 °F (-4° to 131 °F) ±1 Digit / ±0.4 °C (-20 to +55 °C) ±1 Digit
    Resolution
    0.1 °F / 0.1 °C


    Humidity - Capacitive

    Measuring range
    0 to 100 %rH*
    Accuracy
    ±2 %rH (2 to 98 %rH at 77.0 °F / ±2 %RH (2 to 98 %RH) at +25 °C
    < ±1 %rH / year drift at +77 °F / < ±1 %RH / year drift at +25 °C
    ±0.03 %rF/K ±1 Digit
    Resolution
    0.1 %rH
    * Not for condensing atmospheres.

    Dewpoint (calculated)

    Measuring range
    -40° to 50 °Ctd
    Accuracy
    0.0 %rF/K


    General technical data

    Weight
    4.59 oz. / 130 g
    Dimensions
    6 x 2 x 1 in. / 149 x 53 x 27 mm
    Operating temperature
    -4° to 131 °F / -20 to +55 °C
    Housing
    Plastic
    Protection class
    IP54
    Channels
    2 internal
    Product colour
    Black
    Life-time sensor
    Long-term drift of the sensor <1% RH / year (ambient temperature + 25 ° C)
    Standards
    EU-guideline 2014/30/EU; 2011/65/EU
    Measuring rate
    10 s - 24 h
    Battery type
    3 x AIMn type AAA or Energizer
    Battery life
    3 years at 15 min. meas. rate, +25 °C
    Interface
    mini usb, SD card slot
    Memory
    1,000,000 measuring values
    Storage temperature
    -4° to 131 °F / -20 to +55 °C
