Product Description
Protimeter Grainmaster i2 Crop Moisture Meter - GRN3100
Click Here for Protimeter AccessoriesIntegrated moisture and temperature measurement device for grain crops and additional hay/straw bales.
Protimeter Grainmaster i2 uses the ground grain moisture testing method for unrivaled repeatability and accuracy. It can also be used with optional probes to measure temperature in grain, as well as moisture in hay and straw.
The Protimeter Grainmaster i2 is supplied in a pouch with grinder compressor unit, grain cup, sample spoon, brush and Quickcheck. Optional probes can be used with the Grainmaster i2, for integrated moisture and temperature measurement capability.
The Grainmaster is supplied in a pouch with grinder-compressor unit, grain cup, sample spoon, brush and 'Quickcheck'. In addition to the 0-100 relative scale, the 15 pre-programmed calibrations include: Wheat, Barley, Oats, Oilseed Rape, Canola, Linseed, Peas, Corn, Sunflower, Coffee, Soya, Rice, Sorghum, Paddy and Beans.
Protimeter Grainmaster i2 Moisture Meter Datasheet Protimeter Calibration Data
| Weight of Instrument with Grinder-Compressor Unit | 1 kg |
| Dimensions of Unit with Grinder-Compressor Unit | 195 mm length x 185 mm height x 100 mm width |
| Power | x1 6F22R 9V Battery |
| LCD Resolution | 0.1 |
| LDC Technology | Sunlight visible graphical display |
| Operating Temperature Range | 0°C to 50°C |
| Bluetooth | 4.2 BLE |
| Software Upgrade | USB |
| Language | Configurable through settings |
| % H2O Measurement Range | |||
|---|---|---|---|
| Wheat: 11.3 to 29.3 | Canola: 7.0 to 26.0 | Coffee: 9.8 to 23.9 | Rice: 13.2 to 26.5 |
| Oats: 10.9 to 29.3 | Linseed: 7.0 to 16.5 | Soya: 7.4 to 22.2 | Sorghum: 10.2 to 26.9 |
| OSR: 7.0 to 26.0 | Sunflower: 6.2 to 23.0 | Beans: 12.4 to 25.0 | Paddy: 10.4 to 26.2 |
| Barley: 10.9 to 29.3 | Corn: 10.4 to 26.2 | Peas: 12.0 to 30.9 | 0-100 Relative |
| Note: Not all calibrations are for ground samples. | |||
