Product Description
Phase II Digital MACRO Vickers Hardness Tester w/Man Software - 900-398A
Our advanced line of Macro Vickers hardness testers are state-of-the-art, precise testing systems suitable for hardness analysis of metallic specimens in metallography laboratories or production environments.
The Phase II macro-vickers hardness testers are versatile and user-friendly systems.
Designed for the accurate hardness testing of small precision parts, thin materials, case hardened layers and all sorts of steel components. The Phase II 900-398 is our macro-vickers hardness tester, covering the load range from 1kg to 50kg, with digital technology. Conforming to ASTM E-384/92 vickers hardness testers standards, the 900-398 digital vickers hardness tester will offer unmatched repeatability. A perfect rugged performer suited for any environment, the Phase II vickers hardness testers are offered with a 5 year warranty and free lifetime technical support.
The 900-398 Vickers Hardness Tester which includes precision video and measurement software package is engineered to produce a clear indentation and a more precise measurement. By means of a load cell, closed circuit system for control, the CPU controls testing force to load/dwell/unload, allowing for the highest degree of accuracy. The large LCD shows the measuring methods, the testing force, the indentation length, hardness value, the dwell time of the testing force as well as the number of the measurement on its screen.
All information such as diagonal lines length of indentation, hardness values, data statistics and hardness conversions can be displayed on the LCD as well as your laptop or PC.
- Base Machine
- Video Cam w/ Adapter
- Measurement Software
- Large test table
- VShape test table
- 10X Digital Micro Lens
- Bullseye Level
- Adjustable Screw
- Vicker Hardness Block
- RS232 Interface Line
Specifications for Phase II Vickers Hardness Tester Model 900-398
1. Test Forces
9.807ã19.61ã24.52ã29.42ã49.03ã98.07ã196.1ã249.2ã490.3 N 1ã2ã2.5ã3ã5ã10ã20ã30ã50 kgf
2.Carriage Control: automatic loading / holdingup of the load / unloading )
3. Amplification of the Microscope: 100 Ãã 200 Ã
4. Dwell Time of the Test Force: (060)s
5. Min. Graduation Value of the Testing Drum Wheel: 0.125um
6. Testing Field: 1HV2967HV
7. Lens Indentor Switch: With Motorized Turret
8. Output: Builtin Mini Printer RS232
9. Max. height of the specimen : 170 mm
10. Max. width of the specimen : 130mm
11. Objective: 10xã20xã40x selectable
12. Light source: cold light source
13. Power Supply : 110V/220V,60/50Hz
14. Dimension: 535X225X580mm
