Product Description
Onset Trans,0-200A,333mV Out CT,SCT-1250-200 - T-MAG-SCT-200
The Magnelab AC Current 200 Amp AC Current Transformer or CT (Magnelab part # SCT-1250-100) is mounted around a current carrying wire to measure AC Amperage. This CT provides 333mV output proportional to current and is used with the FlexSmart TRMS Module for True RMS measurement of sinusoidal and non-sinusoidal waveforms. The result is accurate current measurement for many types of equipment, including variable frequency drives and switched power sources. One or two CTs can be used with each FlexSmart TRMS Module.
Highlighted Features
Rated input from 00 to 200 AMP Output 0.333 Volt AC at rated current Linearity accuracy ± 1% Accuracy at 10% to 130% of rated current Split-core design for fast, easy installation 8 ft. (2.44m) 22 AWG twisted pair leads 1.25 Opening
In what environment does this sensor operate?
This sensor operates in an indoor environment.
What measurements does this sensor support?
The T-MAG-SCT-200 sensor supports the following measurement: AC Current
Rated input from 20 Amp to 200 Amp Output 0.333 Volt AC at rated current Operates from 30 Hz to 1,000 Hz Phase angle < 2 degrees measured at 50% rated current Linearity accuracy ± 1% 8 ft. twisted-pair lead UL, c(UL) recognized, CE, and RoHS compliant Accuracy at 10% to 130% of rated current Custom output and other parameters are available
